Goliath, 12000 LB, Sentetik Halatlı, UK, 12 V, Integrated Vinç, SIC12000W

[Adnan Çetinel]

Goliath, 12000LB, hem kablolu hem de kablosuz kumandalı, sentetik halatlı, Integrated, 12V Vinç. Kdv dahil, 999.00 TL
online satın almak için: http://www.sahibinden.com/ilan/vasita-yedek-parca-aksesuar-otomobil-arazi-araci-goliath-sentetik-halat-uk-12000lb-vinc-sic12000w-44668706/detay


SIC12000W



12000 lbs Heavy Duty Electric Winch

12000 LBS FEATURES AND SPECIFICATIONS
Rated Line Pull 12000LBS (5440kgs) single line
Motor 12V 6.6hp/4.8kw
Control Remote switch, 12ft(3.7m)lead
Gear train 3 Stage Planetary
Gear train ratio 187.2:1
Braking Action Automatic In-The-Drum
Cable 94ft of 3/8"dianeter (28mof9.1mm diameter)
Main body sealed
Effected protection 5600kg-5750kg
Fairlead 4-Way Roller Fairlead
Battery Leads 2 gauge,72"(183mm)
Finish Dark gray powder coat
Overall Dimensions 21.1"×6.3"×8.6"(537mm×160mm×218mm)
Mounting Bolt Pattern 254mm×114.3mm
Weight N.W.30kg G.W.32kg
Packing Size 57×19×34.5cm 1PC/CTN



[Adnan Çetinel]

Ynt: Goliath, 12000 LB, Sentetik Halatlı, UK, 12 V, Integrated Vinç, SIC12000W


yük, hız ve amp değerleri.


12000LBS LINE SPEED AND AMP DRAW (FIRST LAYER)
Line Pull lbs 0 4000 6000 8000 10000 12000 12300
kg 0 1814 2720 3630 4540 5440 5590
Line Speed ft/min 33.3 16.8 12.8 10.1 8.8 7.6 0
m/min 10.3 5.1 3.9 3.1 2.7 2.3 0
Motor / Amps 85 158 231 302 371 450 200



12000LBS LINE PULL AND CABLE CAPACITY
Layers of cable 1 2 3 4
Rated line pull per layer lbs 12000 9210 8030 6894
kg 5440 4170 3640 3125
Cumulative cable capacity ft 17 41 71 82
m 4.8 12 21 25



[Adnan Çetinel]

Ynt: Goliath, 12000 LB, Sentetik Halatlı, UK, 12 V, Integrated Vinç, SIC12000W

Sentetik halatlı, hem kablolu hem de kablosuz uzaktan kumandalı, entegre tip 12000 lb vinç, 999.00 tl, kdv dahil.



[Adnan Çetinel]

Ynt: Goliath, 12000 LB, Sentetik Halatlı, UK, 12 V, Integrated Vinç, SIC12000W

Sentetik halatlı, hem kablolu hem de kablosuz uzaktan kumandalı, entegre tip 12000 lb vinç, 999.00 tl, kdv dahil.

wireless



[Adnan Çetinel]

Ynt: Goliath, 12000 LB, Sentetik Halatlı, UK, 12 V, Integrated Vinç, SIC12000W

Kablosuz uzaktan kumandalı



[altay41]

Ynt: Goliath, 12000 LB, Sentetik Halatlı, UK, 12 V, Integrated Vinç, SIC12000W

guzelmis Adnan Bey,hayirli satislar



[Adnan Çetinel]

Ynt: Goliath, 12000 LB, Sentetik Halatlı, UK, 12 V, Integrated Vinç, SIC12000W

guzelmis Adnan Bey,hayirli satislar

teşekkürler Altan Bey, tekrar görüşmek üzere.
